Name：Dual Seat Gas-liquid Safety Relief Valve Tester

Model:SV-G05/M26/H61

The Model is designed to test Safety Relief Valves with gas and liquid up to 6000Psi. The tester is equipped with two 40-ton clamping fixtures capable of clamping 1/2” to 12” flanged valves, and 1/2” to 2” NPT valves.
Detailed introduction

•Control console cabinet, powder coated (optional SS)

•Safety Hydraulic Interlock valve prevents accidental release of clamping pressure when valves are under test pressure.

•Valve test range:DN15-300mm

•Test accuracy:+/-0.4%

•Hydraulic Clamping fixture with Safety Interlock

•Panel mounted gauges, valves & controls for ergonomic controls

•40-ton 3-arm clamping fixture., Hydraulic cylinder is operated by an air driven pump
